Vörulýsing
Why you’ll love it
- You get a bike that rides like your favourite trail bike on descents and gives you adaptive assist on the climbs that doesn’t make you feel like a cheat
- Its tiny-but-mighty TQ transmission is tuned for the trail, keeping things quiet so you can stay in the moment, plus it ramps up power with you for a natural ride feel
- The smart charge port, sleek integrated display and discreet controls keep the bike looking and feeling like a traditional mountain bike
- It keeps your ride silky smooth even when the trail gets rowdy thanks to the upgraded RockShox suspension package that offers 150 mm of front and 140 mm of rear travel
- You’ll be able to add on a range extender when you want a little extra fuel in the tank for big days on the bike
It’s right for you if…
You want a lively trail bike that feels like a traditional mountain bike in quick, techy terrain, but gives you a little boost in pedal power on the way back up. You want space-age technology everywhere from motor to drivetrain, and upgraded suspension that keeps you floating on the trail. You don’t want to lose out on the natural experience of mountain biking, and want a refined motor that quietly assists while you ride.
The tech you get
An OCLV Mountain Carbon frame equipped with a fully encased 360 Wh battery and TQ harmonic pin ring transmission with a smart charging port, integrated LED display and discreet handlebar remote. Plus, a 150 mm RockShox Lyrik Select+ fork with DebonAir spring and Charger 2.1 RC damper, and 140 mm RockShox Super Deluxe Select+ rear suspension. The cherry on top? A wireless SRAM GX AXS drivetrain that keeps your cockpit minimalist and clean.
The final word
The Fuel EXe 9.8 is a refined trail bike with just the right amount of power for scorching climbs before turning around to rally though technical and flow trails alike. Its equipped with future-minded technology, like the space-approved TQ transmission and wireless SRAM GX AXS shifting that keeps your cockpit minimalist. Finally, carbon wheels and an upgraded RockShox suspension package keeps you floating on the trail even when the conditions get hairy.
Specification
Frameset
- Frame – OCLV Mountain Carbon, removable battery, internal routing, alloy rocker link, 34.9 mm seat tube, upper chain guide mount, 55 mm chainline, Mino Link, ABP, Boost148, UDH, 140 mm travel
- Fork – RockShox Lyrik Select+, DebonAir spring, Charger 2.1 RC damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 150 mm travel
- Shock – RockShox Super Deluxe Select+ RT, 205mm x 60mm
- Max compatible fork travel – 160mm (575mm axle-to-crown)
Wheels
- Wheel front – Bontrager Line Elite 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 29″
- Wheel rear – Bontrager Line Elite 30, OCLV Mountain Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost148, 12 mm thru axle, 29″
- Skewer rear – Bontrager Switch thru-axle, removable lever
- Tyre Size: S, M, L, XL – Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 29×2.50″
- Tyre Size: S, M, L, XL – Bontrager SE5 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 60 tpi, 29×2.50″
- Tyre part – Bontrager TLR sealant, 180 ml/6 oz
- Rim strip – Bontrager TLR
- Max tyre size – Frame: 29×2.50″, Fork: See manufacturer
E-system
- Battery – TQ 360Wh
- Charger – TQ 4A charger
- Computer – TQ LED display with Bluetooth & ANT+ connectivity
- Motor – TQ-HPR50, 50 Nm, 250 watt maximum continuous rated power, 300 watt peak power
Drivetrain
- Shifter – SRAM GX Eagle AXS, 12 speed
- Rear derailleur – SRAM GX Eagle AXS
- Crank Size: S, M, L, XL – E*thirteen E*spec Plus, 165 mm length
- Crank Size: S, M, L, XL – E*thirteen E*spec Race carbon, 165 mm length
- Chainring – SRAM X-SYNC, 32T, alloy
- Cassette – SRAM Eagle XG-1275, 10-52, 12-speed
- Chain – SRAM GX Eagle, 12-speed
- Max. chainring size 1x: 34T, min 30T
Components
- Saddle – Bontrager Arvada, austenite rails, 138 mm width
- Seatpost Size: S – Bontrager Line Elite Dropper, 100 mm travel, MaxFlow, internal routing, 34.9 mm, 345 mm length
- Seatpost Size: M – Bontrager Line Elite Dropper, 150 mm travel, MaxFlow, internal routing, 34.9 mm, 440 mm length
- Seatpost Size: L – Bontrager Line Elite Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 485 mm length
- Seatpost Size: XL – Bontrager Line Elite Dropper, 200 mm travel, MaxFlow, internal routing, 34.9 mm, 550 mm length
- Handlebar/stem (integrated) Size: S – Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 27.5 mm handlebar rise, 820 mm width, 0-degree stem rise, 35 mm stem length
- Handlebar/stem (integrated)Size: M, L, XL – Bontrager RSL Integrated handlebar/stem, OCLV Carbon, 27.5 mm handlebar rise, 820 mm width, 0-degree stem rise, 45mm stem length
- Grips – Bontrager XR Trail Elite, nylon lock-on
- Brake rotor – SRAM 6-bolt, 200 mm
- Brake Set – SRAM Code R 4-piston hydraulic disc
- Rotor size – Max brake rotor sizes – Frame: 203mm, Fork: see fork manufacturer
Weight
- Weight – M – 18.17 kg (with TLR sealant, no tubes)
- Weight limit – This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg.
