Vörulýsing
Why you’ll love it
- All-new progressive geometry is quick and nimble yet keeps you stable and in control on fast, choppy descents
- This bike is exceedingly versatile and suited to a wide variety of riding styles, including gravel rides, bike-packing and daily commutes
- Massive tyre clearance means you can use tyres up to 45 c for extra traction and stability in any conditions
- Integrated frame bag mounts and rack and mudguard mounts make it easy to carry gear and water
It’s right for you if…
Unlike the pure roadie who measures watts and weighs out meals, you favour epic off-road adventures that probably end with a beer and a bag of chips. But that doesn’t mean you’ll compromise on performance. You expect to get a lot for your hard-earned money, including quality, versatility, durability and a ridiculous amount of fun.
The tech you get
A sturdy aluminium frame with a progressive geometry that’s stable at speed and efficient when you’re grinding up a climb, hidden cables that won’t interfere with bags, rack and mudguard mounts and integrated frame bag mounts, a 2×11 Shimano GRX drivetrain with lower gears for grinding up hills or through rough gravel, hydraulic disc brakes for all-condition stopping power, tubeless-ready rims and wide 700x40c gravel tyres for added stability and traction.
The final word
If the amount of adventure you can get per pound spent is a priority for you, you won’t do better than Checkpoint ALR 5. Quality parts, a durable alloy frame and a wealth of features like extra tyre clearance and customisation options – so you can confidently take on bigger, better adventures.
Frameset
- Frame – 300 Series Alpha Aluminium, tapered head tube, Internal cable routing, 3S chain keeper, T47 BB, rack and mudguard mounts, integrated frame bag mounts, flat-mount disc, 142×12 mm thru-axle
- Fork – Checkpoint carbon, tapered carbon steerer, rack mounts, mudguard mounts, flat-mount disc, 12×100 mm thru axle
- Frame fit – Gravel
Wheels
- Hub front – Bontrager alloy, sealed bearing, CenterLock disc, 100×12 mm thru axle
- Skewer front – Bontrager Switch thru axle, removable lever
- Hub rear – Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142×12 mm thru axle
- Skewer rear – Bontrager Switch thru-axle, removable lever
- Rim Size: 49, 52, 54, 56, 58, 61 – Bontrager Paradigm, Tubeless Ready, 24-hole, 21 mm width, Presta valve
- Rim Size: 49, 52, 54, 56, 58, 61 – Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21 mm width, Presta valve
- Spokes – 14 g stainless steel
- Tyre – Bontrager GR1 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 120 tpi, 700 x 40 c
- Tyre part – Bontrager TLR sealant, 180 ml/6 oz
- Rim strip – Bontrager Aeolus XXX rim strip
- Max tyre size – 700x45c / 650×2.1″ Bontrager tyres
Drivetrain
- Shifter – Shimano GRX hydraulic disc
- Front derailleur – Shimano GRX RX810, braze-on
- Rear derailleur – Shimano GRX RX810, long cage, 34T max cog
- Crank Size: 49 – Shimano GRX RX600, 46/30, 165 mm length
- Crank Size: 52 – Shimano GRX RX600, 46/30, 170 mm length
- Crank Size: 54, 56 – Shimano GRX RX600, 46/30, 172.5 mm length
- Crank Size: 58, 61 – Shimano GRX RX600, 46/30, 175 mm length
- Bottom bracket – Praxis, T47 threaded, internal bearing
- Cassette – Shimano 105 HG700-11, 11-34, 11 speed
- Chain – Shimano HG601
- Max. chainring size 1x: 44T SRAM or 50T Shimano, 2x: 50/34
Components
- Saddle Size: 49, 52 – Bontrager Verse Comp, steel rails, 155 mm width
- Saddle Size: 54, 56, 58, 61 – Bontrager Verse Comp, steel rails, 145 mm width
- Seatpost – Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length
- Handlebar Size: 49 – Bontrager Elite Gravel, 38 cm width
- Handlebar Size: 52 – Bontrager Elite Gravel, 40 cm width
- Handlebar Size: 54, 56 – Bontrager Elite Gravel, 42 cm width
- Handlebar Size: 58, 61 – Bontrager Elite Gravel, 44 cm width
- Handlebar tape Bontrager Supertack Perf tape
- Stem Size: 49 – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
- Stem Size: 52, 54 – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
- Stem Size: 56, 58 – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
- Stem Size: 61 – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length
- Head set – FSA Integrated, sealed cartridge bearing, 1-1/8″ top, 1.5″ bottom
- Brake – Shimano RX400 hydraulic disc
- Brake rotor – Shimano RT70, CentreLock, 160 mm
- Rotor size – Max brake rotor sizes: 160 mm front and rear
Weight
- Weight – 56 – 9.75 kg
- Weight limit – This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg.
