Racer, Gravel, Cyclocross, Touring


Stærðir til viðmiðunar. Fleira en hæð og innri saumur (inseam) getur skipt máli þegar stærð á hjóli er valin. Sölumenn í verslun geta aðstoðað við að finna út réttu stærðina.


StellstærðHæðInseam
44 cm150-155 cm71-73 cm
47 cm152-159 cm71-75 cm
49 cm158-163 cm74-77 cm
50 cm157-164 cm74-77 cm
51 cm162-168 cm76-79 cm
52 cm162-169 cm76-79 cm
54 cm167-174 cm78-82 cm
56 cm173-180 cm81-85 cm
58 cm179-186 cm84-87 cm
60 cm184-191 cm86-90 cm
62 cm189-196 cm89-92 cm

Stærðartafla fyrir eftirfarandi tegundir: Domane, Émonda, Madone, Crossrip, Checkpoint, Boone, 520 og 920.

Domane AL 4 (2022)

289.990 kr.

Domane AL 4 Disc combines the smooth, comfortable qualities of an advanced alloy frame with the performance of higher-quality parts. It features an upgraded drive train and crisp hydraulic disc brakes for a fast road bike perfect for competitive group rides and even races.

Síminn Pay Léttkaup
kr/mán
(m.v. mán)

mán.

Miðað við greiðslur á % vöxtum.

Aðeins % lántökugjald og kr. færslugjald á mánuði.

Árleg hlutfallstala kostnaðar: %.

Heildarkostnaður: kr.

Vörunúmer: 0100637395 Flokkur: Brand:
Stærðartafla
  • A light, comfortable frame and quality parts make it an amazing platform for long, fast group rides
  • The unique IsoSpeed Carbon fork, which swoops forward toward the dropouts, absorbs vibrations from the road so your arms won’t fatigue as quickly
  • Hydraulic disc brakes give you more precise and consistent stopping power in any conditions
  • Bigger tyre clearance lets you run wider tyres for more traction and stability on rail trails and other light gravel roads
  • DuoTrap S compatibility makes it easy to wirelessly track your rides, so you can set goals and watch yourself reach them

Frameset

  • Frame – 100 Series Alpha Aluminium, tapered head tube, internal routing, mudguard mounts, DuoTrap S-compatible, flat-mount disc, 142×12 mm thru axle
  • Fork – Domane AL carbon, tapered alloy steerer, internal brake routing, mudguard mounts, flat-mount disc, 12×100 mm thru axle
  • Frame fit – Endurance

Wheels

  • Hub front – Formula RX-512 alloy, 6-bolt, 100×12 mm thru axle
  • Skewer front – Bontrager Switch thru axle, removable lever
  • Hub rear – Formula RX-142 alloy, 6-bolt, Shimano 11-speed freehub, 142×12 mm thru axle
  • Skewer rear – Bontrager Switch thru-axle, removable lever
  • Rim – Bontrager Affinity Disc, Tubeless Ready, 24-hole, 21 mm width, Presta valve
  • Tyre – Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700×32 c
  • Max tyre size – 35c without fenders, 32c with fenders

Drivetrain

  • Shifter – Shimano Tiagra R4725, short-reach lever, 10-speed
  • Front derailleur – Shimano Tiagra 4700, 31.8 mm clamp
  • Rear derailleur – Shimano Tiagra 4700, long cage, 34T max cog
  • Crank Size: 44 – Shimano Tiagra 4700, 50/34, 165 mm length
  • Crank Size: 49, 52 – Shimano Tiagra 4700, 50/34, 170 mm length
  • Crank Size: 54, 56 – Shimano Tiagra 4700, 50/34, 172.5 mm length
  • Crank Size: 58, 61 – Shimano Tiagra 4700, 50/34, 175 mm length
  • Bottom bracket – Prowheel PW-BB73+, 68/73 mm, threaded external
  • Cassette – Shimano 10-speed, 11-32T
  • Chain – Shimano Tiagra HG54, 10-speed

Components

  • Saddle Size: 44, 49, 52 – Bontrager P3 Verse Comp, steel rails, 155 mm width
  • Saddle Size: 54, 56, 58, 61 – Bontrager P3 Verse Comp, steel rails, 145 mm width
  • Seatpost Size: 44, 49 – Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 250 mm length
  • Seatpost Size: 52, 54, 56, 58, 61 – Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 330 mm length
  • Handlebar Size: 44, 49 – Bontrager Comp VR-S, alloy, 31.8 mm, 81 mm reach, 118 mm drop, 38 cm width
  • Handlebar Size: 52 – Bontrager Comp VR-S, alloy, 31.8 mm, 81 mm reach, 118 mm drop, 40 cm width
  • Handlebar Size: 54, 56 – Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 42 cm width
  • Handlebar Size: 58, 61 – Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 44 cm width
  • Handlebar tape – Bontrager Supertack Perf tape
  • Stem Size: 44 – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
  • Stem Size: 49 – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
  • Stem Size: 52, 54 – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
  • Stem Size: 56, 58 – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length
  • Stem Size: 61 – Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length
  • Head set – FSA Integrated, sealed cartridge bearing, 1-1/8″ top, 1.5″ bottom
  • Brake – Shimano Tiagra hydraulic disc
  • Brake rotor Size: 44, 49, 52, 54, 56, 58, 61 – Shimano RT66, 160 mm, 6-bolt
  • Brake rotor Size: 44, 49, 52, 54, 56, 58, 61 – Shimano RT66, 6-bolt, 160 mm

Weight

  • Weight – 56 – 10.48 kg
  • Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).

Nánari upplýsingar

Litur

Gloss Black Matte

Stærð

52 cm, 54 cm, 56 cm, 58 cm
