Vörulýsing
Specs
Frameset
- Frame
-
Frame made of premium Alpha Platinum aluminum, top-loading Bosch CompactTube battery, internal cable routing at the cockpit, luggage rack and mudguards, adjustable dropouts
- Fork
-
SR Suntour Mobie 34, tapered steerer tube, air spring, adjustable rebound and compression, lockout, 100mm QR, 80mm travel
Wheels
- VR hub
-
Shimano TC500, Centerlock, 110x15mm thru axle
- rear hub
-
Shimano TC500-HM
- HR quick release
-
Bontrager Switch thru-axle, removable lever
- *Rim
-
Sizes: S, M, L, XL
Bontrager Kovee, double-wall rim, tubeless ready, 28-hole, 23 mm internal width, Presta valveSizes: S, M, L, XL
Bontrager Kovee, double-wall rim, tubeless ready, 32-hole, 23 mm internal width, Presta valve - spokes
-
14 g, stainless steel, black
- Tires
-
Bontrager E6 Hard Case Lite, Reflective, Wire Bead Core, 60 TPI, 27.5 x 2.4
- Max. tire size
- Frame: 27.5 x 2.40″, Fork: see manufacturer’s specifications
E-system
- Battery
-
Bosch PowerTube 800 Wh, Smart System
- charger
-
Bosch standard charger 4 A, 230 V, Smart System
- Controller
-
Bosch Kiox 500, smart system
- computer
-
Bosch LED remote, smart system
- Motor
-
Bosch Smart System PX, 90 Nm, 250 W, 25 km/h max. support
Drivetrain
- gearshift lever
-
Shimano CUES U6000 with optical gear indicator, 10-speed
- shifter
-
Shimano CUES U6000 GS
- crank
-
ProWheel, aluminum, 170 mm crank arm length
- chainring
-
Aluminum, 40 teeth, narrow-wide tooth profile, chain guard
- cassette
-
Shimano CUES LG400, LINKGLIDE, 11-48 teeth, 10-speed
- Chain
-
Shimano LG500
- pedal
-
Bontrager City Pedals
- Max. chainring size
- 1x: 50Z.
Components
- saddle
-
Bontrager Commuter Comp
- *Seatpost
-
Size: S, M
Spring-loaded, aluminum, 300mm long with adjustable spring tensionSize: L, XL
Spring-loaded, aluminum, 350mm long with adjustable spring tension - handlebars
-
Aluminum, 31.8 mm clamp, 25 mm rise, 630 mm width
- handles
-
Trek Ergonomic PRO, screw clamp
- stem
-
Bontrager alloy, 31.8mm clamp, adjustable rise, Blendr compatible, 80mm length
- *Brake
-
Sizes: S, M, L, XL
Shimano MT401 / MT420 hydraulic disc brake, 180 mm disc diameterSizes: S, M, L, XL
Shimano BR-MT420 hydraulic disc brake - *Brake disc
-
Sizes: S, M, L, XL
Shimano RT30, Centerlock disc mount, 180 mmSizes: S, M, L, XL
Shimano RT30, Center Lock, 203mm - brake disc diameter
- Max. brake disc diameter: Frame: 203 mm, Fork: See manufacturer’s specifications
Accessories
- Light
-
Sizes: S, M, L, XL
Trek LED rear lightSizes: S, M, L, XL
Trek LED headlight - Side stand
-
Pletscher Comp Flex 40
Weight
- Weight
- M – 27.30 kg (without battery)
- Max. weight
- This bicycle has a maximum weight limit (bicycle, rider and load) of 160 kg.
Sizing
Sizing
How tall are you?
To measure your height, stand up straight, barefoot, with your back, heels, shoulders and head all touching a wall. While looking straight ahead, place a book or straight edge on your head and slowly push it against the wall. Your straight edge should be parallel with the floor. Mark the spot where the bottom of the book is touching the wall. The distance from the marked spot to the floor is your height.
What is your inside leg?
How to measure: Stand barefoot with your back straight and against a wall. Tuck a ruler or something that extends to the floor between your legs. Using both hands, and keeping it level, pull the ruler up into your crotch as if you were sitting on the saddle. Measure the distance from the top edge of the ruler to the ground to find your inside leg measurement. Your inside leg is very important to your final bike size so please measure carefully.
Sizes
| Size | Driver’s height | Inseam length |
|---|---|---|
| S |
147 – 155 cm 4’10“ – 5’1″ |
69 – 88 cm 27″ – 35″ |
| M |
155 – 173 cm 5’1″ – 5’8″ |
77 – 96 cm 30″ – 38″ |
| L |
170 – 185 cm 5’7″ – 6’1″ |
80 – 99 cm 31″ – 39″ |
| XL |
185 – 203 cm 6’1″ – 6’8″ |
86 – 105 cm 34″ – 41″ |
