tegundir: Verve, DS (Dual Sport), FX, Allant+ og Verve+.
Vörulýsing
It’s right for you if…
You’re looking for an e-bike with equal parts performance, comfort and sleek looks. You also want the connection and customisation of Bosch’s smart system, including activity tracking, navigation and Bluetooth connectivity.
The tech you get
A sleek hydroformed aluminium frame with a lowstep design that makes it easier to hop on and off, a fully-integrated 625 Wh Bosch smart system battery, a powerful Bosch smart system CX (250 W, 85 Nm) drive unit that helps you sustain speeds of up to 20 mph (25 km/h in Europe) and a Bosch smart system LED remote with a Purion 200 display. Plus, a suspension fork with lockout, a 10-speed Shimano CUES drivetrain, hydraulic disc brakes, an integrated front and rear lighting system, mudguards and a rear rack.
The final word
The Allant+ 7 is a sophisticated e-bike equipped with the powerful Bosch smart system, a fully-integrated battery, a suspension fork that soaks up bumps, useful features for daily riding and a quality parts group chosen for reliability and durability over the long haul.
Why you’ll love it
- A powerful Bosch smart system gives you plenty of support and responsiveness, plus Bluetooth connectivity for tracking activity, planning rides and more
- The streamlined, full-colour Purion 200 display gives you the ride details you want without getting in the way
- Trek’s Removable Integrated Battery (RIB) system looks great and is super user-friendly: it fully hides the battery in the frame and makes it easy to remove for off-bike charging and storage
- The fork’s lockout feature ensures that you’re always riding efficiently: close it for smooth tarmac, open it up on rougher roads
- It really is ready to roll, with included accessories like mudguards and lights that run off the battery
Specification
Frameset
- Frame – High-performance hydroformed e-bike frame, Removable Integrated Battery, Motor Armor, internal cable routing, post-mount disc
- Fork – SR Suntour XCR32, coil spring, preload adjuster, lockout,100 mm QR, 63 mm travel
- Max compatible fork travel 63mm
Wheels
- Hub front – Shimano Tourney HB-QC300, centerlock
- Hub rear – Shimano FH-QC300-HM, 32-hole, CentreLock, 8-/9-/10-/11-speed, 135×5 mm QR
- Rim – Bontrager Line TLR 30, Tubeless-Ready, 32-hole, Presta valve
- Tyre – Schwalbe G-One, Performance, RaceGuard, with reflective strip, 57-584
- Max tyre size – 27.5 x 2.40″
E-system
- Battery – Bosch PowerTube 625 Wh, smart system
- Charger – Bosch standard 4A, 230V, smart system
- Computer – Bosch Purion 200
- Motor – Bosch Performance Line CX, smart system, magnesium motor body, 85 Nm
Drivetrain
- Shifter – Shimano CUES U6000 w/optical gear display, 10-speed
- Rear derailleur – Shimano CUES U6000 GS
- Crank Size: S, M – ProWheel alloy, 170 mm length
- Crank Size: L – ProWheel alloy, 175 mm length
- Chainring – ProWheel 40T narrow/wide steel, w/alloy guard
- Cassette – Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed
- Chain – Shimano LG500, 9/10/11-speed
- Pedal – slip-proof pedals with reflectors
- Max. chainring size 1x: 48T
Components
- Saddle – Bontrager Commuter Comp
- Seatpost Size: S, M – Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
- Seatpost Size: L – Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
- Handlebar – Alloy lowriser, 31.8 mm, 25 mm rise, 11-degree backsweep, 690 mm width
- Grips – Herrmans Clik, ergonomic, lock-on
- Stem Size: S, M – Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 85 mm length
- Stem Size: L – Bontrager alloy, 31.8 mm clamp, adjustable rise, Blendr-compatible, 105 mm length
- Head set – FSA Integrated, sealed cartridge bearing, 1-1/8″ top, 1.5″ bottom
- Brake – Shimano MT200 hydraulic disc
- Brake rotor Size: S, M, L – Shimano RT30, CentreLock, 180 mm
- Brake rotor Size: S, M, L – Shimano EM300, CentreLock, 180 mm
- Rotor size – Max brake rotor sizes: 180 mm front and rear
Accessories
- Light Size: S, M, L – Spanninga SOLO for e-bike
- Light Size: S, M, L – Herrmans H-Black MR9-E, 60lux, LED, headlight
- Kickstand – Pletscher Comp Flex 18
- Cargo rack – MIK-compatible alloy rear rack, maximum load 25 kg
- Mudguard Size: S, M, L – SKS plastic, rear
- Mudguard Size: S, M, L – SKS plastic, front
Weight
- Weight M – 22.30 kg (excluding battery)
- Weight limit – This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg.
